| Model Variations |
CS2731-BK |
| Panel |
|
| Type |
IPS |
| Backlight |
Wide-Gamut LED |
| Size |
27.0″ (68.5 cm) |
| Native Resolution |
2560 x 1440 (16:9 aspect ratio) |
| Viewable Image Size (H x V) |
596.7 x 335.7 mm |
| Pixel Pitch |
0.233 x 0.233 mm |
| Pixel Density |
109 ppi |
| Display Colors |
USB Type-C, DisplayPort, HDMI: 1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT)
DVI: 16.77 million colors, 8-bit display (from a palette of 278 trillion, 16-bit LUT) |
| Viewing Angles (H / V, typical) |
178°, 178° |
| Brightness (typical) |
350 cd/m2 |
| Contrast Ratio (typical) |
1000:1 |
| Response Time (typical) |
10 ms (gray-to-gray) |
| Color Gamut (typical) |
Adobe RGB: 99% |
| Video Signals |
|
| Input Terminals |
USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 1.4), DVI-D (HDCP 1.4) |
| Digital Scanning Frequency (H / V) |
USB Type-C, DisplayPort, DVI: 26 – 89 kHz, 23 – 61 Hz
HDMI: 15 – 89 kHz, 23 – 61 Hz |
| USB |
|
| Upstream |
USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 60 W max.), USB 3.1 Gen 1: Type-B |
| Downstream |
USB 3.1 Gen 1: Type-A x 2
USB 2.0: Type-A x 2 |
| Power |
|
| Power Requirements |
AC 100 – 240 V, 50 / 60 Hz |
| Typical Power Consumption |
34 W |
| Maximum Power Consumption |
159 W |
| Power Save Mode |
1.0 W or less |
| Features & Functions |
|
| Digital Uniformity Equalizer |
Yes |
| Preset Modes |
User, Adobe RGB, sRGB, Calibration |
| OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Others |
Color Adjustment, Input Color Format, YUV Color Matrix, Input Range, Noise Reduction, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority |
| Physical Specifications |
|
| Dimensions (Landscape, W x H x D) |
638 x 404.1 – 559.1 x 265 mm |
| Dimensions (Without Stand, W x H x D) |
638 x 378.2 x 75 mm |
| Net Weight |
10.1 kg |
| Net Weight (Without Stand) |
6.5 kg |
| Height Adjustment Range |
155 mm |
| Tilt |
35° Up, 5° Down |
| Swivel |
344° |
| Pivot |
90° |
| Hole Spacing (VESA Standard) |
100 x 100 mm |
| Environmental Requirements |
|
| Operating Temperature |
0 – 35°C |
| Operating Humidity (R.H., non condensing) |
20 – 80% |
| Certifications & Standards (Please contact EIZO for the latest information.) |
CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics |
| Dedicated Software |
|
| Easy Screen-to-Print Color Matching Tool Quick Color Match |
Supported |
| Proprietary Software |
|
| Color Management Software ColorNavigator 7 |
Supported |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
| Signal Cables |
USB Type-C (2 m), HDMI (2 m) |
| Others |
AC power cord, USB Type-A – USB Type-B cable (2 m), Setup guide, Warranty card, VESA mounting screw x 4 |
| Warranty |
5 Years 2 5 |
